capability

Br

Hcb

Hcj

(BH)max

TW*
L/D=0.7

units

T
KGs

KA/m
KOe

KA/m
KOe

KJ/㎡
MGOe

NO.

grade

Max

Min

Max

Min

Max

Min

°C

1

N35

1.21

1.17

899

876

≥955

279

263

≤80

12.1

11.7

11.3

11

≥12

35

33

2

N38

1.26

1.22

923

876

≥955

303

287

≤80

12.6

12.2

11.6

11

≥12

38

36

3

N40

1.29

1.26

923

876

≥955

318

303

≤80

12.9

12.6

11.6

11

≥12

40

38

4

N42

1.33

1.3

926

876

≥955

334

318

≤80

13.3

13

11.6

11

≥12

42

40

5

N45

1.37

1.33

926

876

≥955

358

342

≤80

13.7

13.3

11.6

11

≥12

45

43

6

N48

1.42

1.36

926

876

≥955

382

358

≤80

14.2

13.6

11.6

11

≥12

48

45

7

N50

1.45

1.41

907

828

≥876

398

382

≤70

14.5

14.1

11.4

11

≥11

50

48

8

N52

1.48

1.17

907

828

≥876

414

394

≤70

14.8

11.7

11.4

10.5

≥11

52

49.5

9

N35M

1.21

1.17

915

892

≥1114

279

263

≤100

12.1

11.7

11.5

11.2

≥14

35

33

10

N38M

1.26

1.22

931

907

≥1114

303

287

≤100

12.6

12.2

11.7

11.4

≥14

38

36

11

N40M

1.29

1.26

947

907

≥1114

318

303

≤100

12.9

12.6

11.9

11.4

≥14

40

38

12

N42M

1.33

1.3

947

907

≥1114

334

318

≤100

13.3

13

11.9

11.4

≥14

42

40

13

N45M

1.37

1.33

955

907

≥1114

358

334

≤100

13.7

13.3

12

11.4

≥14

45

42

14

N48M

1.42

1.36

955

907

≥1114

382

358

≤100

14.2

13.6

12

11.4

≥14

48

45

15

N33H

1.17

1.14

876

820

≥1353

263

247

≤120

11.7

11.4

11

10.3

≥17

33

31

16

N35H

1.21

1.17

907

860

≥1353

279

263

≤120

12.1

11.7

11.4

10.8

≥17

35

33

17

N38H

1.26

1.22

947

907

≥1353

303

287

≤120

12.6

12.2

11.9

11.4

≥17

38

36

18

N40H

1.29

1.26

947

907

≥1353

318

303

≤120

12.9

12.6

11.9

11.4

≥17

40

38

19

N42H

1.33

1.3

947

907

≥1353

334

318

≤120

13.3

13

11.9

11.4

≥17

42

40

20

N44H

1.36

1.33

947

907

≥1274

350

334

≤110

13.6

13.3

11.9

11.4

≥16

44

42

21

N30SH

1.12

1.08

844

804

≥1592

239

223

≤150

11.2

10.8

10.6

10.1

≥20

30

28

22

N33SH

1.17

1.14

876

820

≥1592

263

247

≤150

11.7

11.4

11

10.3

≥20

33

31

23

N35SH

1.21

1.17

907

860

≥1592

279

263

≤150

12.1

11.7

11.4

10.8

≥20

35

33

24

N38SH

1.26

1.22

947

907

≥1592

303

287

≤150

12.6

12.2

11.9

11.4

≥20

38

36

25

N40SH

1.29

1.26

947

907

≥1592

318

303

≤150

12.9

12.6

11.9

11.4

≥20

40

38

26

N42SH

1.33

1.3

947

907

≥1512

334

318

≤140

13.3

13

11.9

11.4

≥19

42

40

27

N28UH

1.08

1.04

812

780

≥1990

223

207

≤180

10.8

10.4

10.2

9.8

≥25

28

26

28

N30UH

1.12

1.08

844

804

≥1990

239

223

≤180

11.2

10.8

10.6

10.1

≥25

30

28

29

N33UH

1.17

1.14

876

820

≥1990

263

247

≤180

11.7

11.4

11

10.3

≥25

33

31

30

N335UH

1.21

1.17

907

860

≥1990

279

263

≤180

12.1

11.7

11.4

10.8

≥25

35

33

31

N38UH

1.26

1.22

907

860

≥1990

303

287

≤180

12.6

12.2

11.4

10.8

≥25

38

36

32

N40UH

1.29

1.26

907

860

≥1990

303

289

≤180

12.9

12.6

11.4

10.8

≥25

40

38

33

N28EH

1.08

1.04

812

780

≥2388

223

207

≤200

10.8

10.4

10.2

9.8

≥30

28

26

34

N30EH

1.12

1.08

844

804

≥2388

239

223

≤200

11.2

10.8

10.6

10.1

≥30

30

28

35

N33EH

1.17

1.14

876

820

≥2388

263

247

≤200

11.7

11.4

11

10.3

≥30

33

31

36

N35EH

1.21

1.17

907

860

≥2388

279

263

≤200

12.1

11.7

11.4

10.8

≥30

35

33

37

N38EH

1.26

1.22

907

860

≥2388

303

287

≤200

12.6

12.2

11.4

10.8

≥30

38

36

Note:Working temperature is tested under 20°C ±2℃,the inevitable loss of magnetic force is no more than 5%.
